2D numerical model for river-ice processes based upon body-fitted coordinate
-
摘要: 为精确模拟流动边界条件,克服边界形状复杂、长宽尺度相差悬殊及由于水位变化引起计算边界变化等困难,针对天然河道边界弯曲复杂等特点,应用水动力学和热力学等原理,建立了适体坐标下的二维河冰数值模型,模型主要包括流速场,水温沿河道变化,水内冰浓度分布,面冰输移,冰盖推进、稳定和消融,冰盖下冰的输移、堆积和冲蚀等,考虑了冰盖底部水中冰堆积和冰盖前沿形状对封冻过程的影响。采用MacCormack步进格式计算方法,并应用黄河河曲段实测资料对数值模拟结果进行了验证。验证结果表明,提出的数值模型能较好地体现河道的封冻过程。Abstract: To simulate accurately the complicated boundary conditions and overcome the problems caused by wide gap of scale between length and width,and change of computational boundary conditions as water-level variations,a 2D river-ice numerical model based upon the body-fitted method is developed by using the principles of hydrodynamics and thermodynamics and considering the influence of the frazil ice accumulating under ice cover and the shape of freezing fringe of ice cover during the river-ice process. The model is capable of determining the velocity field,the distribution of water temperature,the concentration distribution of the frazil ice,transportation of the floating ice,the progression,stability and thaw of ice cover and the transportation,accumulation and erosion of ice under ice cover MacCormack scheme is used to solve the equations.The model is validated through the field observations in Hequ reach of the Yellow river. The results show that the 2D numerical model presented is capable of simulating the river-ice process with accuracy.
-
Keywords:
- river-ice regime /
- natural river /
- body-fitted coordinate /
- 2D river-ice model
-
-
[1] 茅泽育,吴剑疆,张磊,等.天然河道冰塞演变发展的数值模拟[J].水科学进展,2003,14(6):700-705. [2] 茅泽育,吴剑疆,余云童.河冰生消演变及其运动规律的研究进展[J].水力发电学报,2002(1):153-161. [3] 王永填.河冰数值模型及河渠冬季输水冰情特性研究[D].北京:清华大学,1999. [4] 吴剑疆.河道中冰情形成演变机理分析及冰塞和水内冰数值模拟[D].北京:清华大学,2002. [5] Smith T,Ettema R.Flow resistance in ice-covered alluvial channels[J].Journal of hydraulic engineering,123(7):1997.592-599. [6] 茅泽育,马吉明,佘云童,等.封冻河道的阻力研究[J].水利学报,2002,(5):59-64. [7] 吴剑疆,茅泽育,王爱民,等.河道中水内冰演变发展的数值计算[J].清华大学学报(自然科学版),2003,43(5):702-705. [8] 付辉,伊明昆,尹运基,等.冰塞水位分析[J].水科学进展,2006,17(1):102-107. [9] Ashton G D.Froude criterion for ice block stability[J].Journal of Glaciolngy,1974,13(8):307-313. [10] Pariset E,Hausser R.Formation and evolution of ice covers on rivers[J].Transaction of engineering institute of Canada,1961,5(1):41-49. [11] Lal A M W,Shen H T.A mathematical model for river-ice processes[J].Journal of hydraulic engineering,ASCE,1991,117(7):903-923. [12] Shen H T,Wang D S.Under cover transport and accumulation of frazil granules[J].Journal of Hydraulic Engineering,ASCE,1995,120(2):184-195. [13] Jain S C,Ettema R.Minimization of frazil-ice production by river-flow regulation[J].Journal of Hydraulic Engineering,ASCE,1989,115(9):1256-1274. [14] Matousek V.Regularity of the freezing up of the heat exchange between water body and water surface[A].Proceedings of IAHR Symposium On Ice[C].Iowa:IAHK,1986.187-200. [15] 山西省河曲县防汛抗旱指挥部.黄河河曲冰塞观测资料汇编[R].河曲市:山西省河曲市轻印刷服务中心,1993.
