泄洪雾化降雨模型相似性探讨

周辉, 吴时强, 陈惠玲

周辉, 吴时强, 陈惠玲. 泄洪雾化降雨模型相似性探讨[J]. 水科学进展, 2009, 20(1): 58-62.
引用本文: 周辉, 吴时强, 陈惠玲. 泄洪雾化降雨模型相似性探讨[J]. 水科学进展, 2009, 20(1): 58-62.
ZHOU Hui, WU Shi-qiang, CHEN Hui-ling. Discussion on the scale effect of discharge atomization-rainfall model[J]. Advances in Water Science, 2009, 20(1): 58-62.
Citation: ZHOU Hui, WU Shi-qiang, CHEN Hui-ling. Discussion on the scale effect of discharge atomization-rainfall model[J]. Advances in Water Science, 2009, 20(1): 58-62.

泄洪雾化降雨模型相似性探讨

基金项目: 国家自然科学基金资助项目(50579084);雅砻江水电开发联合基金资助项目
详细信息
    作者简介:

    周辉(1966- ),男,湖北钟祥人,高级工程师,主要从事水工水力学研究.E-mail:hzhou@nhri.cn

  • 中图分类号: TV135.2

Discussion on the scale effect of discharge atomization-rainfall model

Funds: The study is financially supported by the National Natural Science Foundation of China (No.50579084)
  • 摘要: 泄洪雾化影响的研究和预测目前仍然以大比尺模型试验研究为主,但模型缩尺效应是制约这一方法准确预报泄洪雾化影响范围及程度的关键因素。根据乌江渡水电站泄洪雾化原型观测资料,通过系列模型试验研究,分析了水流Re和We数对泄洪雾化降雨强度的影响,对泄洪雾化雨强的模型试验值与原型观测结果之间的相似关系进行了探索,研究了雾化降雨影响区域的不同比尺模型试验测试结果之间的几何相似性。
    Abstract: A series model method is adapted to the preliminary study of scale effect of discharge atomization-rainfall (A-R) model with the field observation result of discharge atomization for Wujiangdu power station.The effect of Re and We numbers of flow on the A-R intensity is analyzed.A conversion relationship of A-R intensity between prototype and model results is developed.The similitude criteria of the A-R range followed by discharge atomization model is discussed,and the conclusion is achieved that the surface tension of discharge A-R model is ignored when We number is larger than 500.
  • [1] 周辉.泄洪雾化溅雨研究[D].南京:南京水利科学研究院,1990.(ZHOU Hui.Study on splash rain of flood discharge atomization[D].Nanjing:Nanjing Hydraulic Research Institute,1990.(in Chinese))
    [2] 柴恭纯,陈惠玲,姜树海.高坝泄流雾化及其影响研究——二滩水电站泄流雾化及其影响研究总报告[R].南京:南京水利科学研究院,1990.(CHAI Gong-chun,CHEN Hui-ling,JIANG Shu-hai.Research on discharge atomization of high dam and related influences-summary report of research on the discharge atomization of Ertan hydropower station and related influences[R].Nanjing:Nanjing Hydraulic Research Institute,1990.(in Chinese))
    [3] 周辉,陈惠玲,吴时强.宽尾墩的泄洪消能效果与雾化影响[J].水力发电学报,2008,27(1):58-63.(ZHOU Hui,CHEN Hui-ling,WUShi-qiang.Flood discharge & energy dissipation effects and atomization influences of wide flange pier[J].Journal of Hydroelectric Engineering,2008,27(1):58-63.(in Chinese))
    [4] 吴时强,吴修锋,周辉,等.底流消能方式水电站泄洪雾化模型试验研究[J].水科学进展,2008(1):84-88.(WU Shi-qiang,WU Xiu-feng,ZHOU Hui,et al.Model experiment study of effect of dischargeatomization for energy dissipation by hydraulic jump[J].Advances in Water Science,2008(1):84-88.(in Chinese))
    [5] 水电部中南勘测设计院.乌江渡水电站高速水流原型观测成果总报告[R].长沙:水电部中南勘测设计院,1983.(Central Southern Geotechnical Design Institute,Ministry of Hydropower.Summary report on prototype observation resultsof high-speed water flow of Wujiangdu hydropower station[R].Changsha:Central Southern Geotechnical Design Institute,Ministry of Hydropower.1983.(in Chinese))
