含挺水植物和沉水植物水流紊动特性

王忖, 王超

王忖, 王超. 含挺水植物和沉水植物水流紊动特性[J]. 水科学进展, 2010, 21(6): 816-822.
引用本文: 王忖, 王超. 含挺水植物和沉水植物水流紊动特性[J]. 水科学进展, 2010, 21(6): 816-822.
shu
WANG Cun, WANG Chao. Turbulent characteristics in open-channel flow with emergent and submerged macrophytes[J]. Advances in Water Science, 2010, 21(6): 816-822.
Citation: WANG Cun, WANG Chao. Turbulent characteristics in open-channel flow with emergent and submerged macrophytes[J]. Advances in Water Science, 2010, 21(6): 816-822.
shu

含挺水植物和沉水植物水流紊动特性

  • 1.

    浅水湖泊综合治理与资源开发教育部重点实验室, 江苏, 南京, 210098;

  • 2.

    河海大学力学与材料学院, 江苏, 南京, 210098;

  • 3.

    河海大学环境学院, 江苏, 南京, 210098

基金项目: 国家重点基础研究发展计划(973)资助项目(2008CB418203);浅水湖泊综合治理与资源开发教育部重点实验室资助(2008KJ004)
详细信息
    作者简介:

    王忖(1974- ),女,河北辛集人,讲师,主要从事流体力学研究.E-mail:Wangcun5158@sina.com

  • 中图分类号: TV133

Turbulent characteristics in open-channel flow with emergent and submerged macrophytes

  • 1.

    Ministry of Education Key Laboratory of Integrated Regulation and Resources Development on Shallow Lakes, Nanjing 210098, China;

  • 2.

    College of Mechanics and Materials, Hohai University, Nanjing 210098, China;

  • 3.

    College of Environment, Hohai University, Nanjing 210098, China

Funds: The study is financially supported by the National Basic Research Program of China(No.2008CB418203).

HTML全文

    摘要
  • 摘要: 在一定的水动力条件下,不同水生植物对水流结构改变的程度及对底泥再悬浮的影响由于其形态结构的差异有所不同.在玻璃水槽中铺设太湖底泥并种植天然沉水植物(水蕨)和挺水植物(菖蒲),通过水槽实验,用三维声学多普勒流速仪ADV对植物段紊流特性进行测量研究,分析含水生植物明渠水流的水力特性及底泥再悬浮规律.结果表明:含沉水植物和挺水植物明渠水流的垂向流速分布各自遵循不同的规律;其紊动强度和雷诺应力具有明显的各向异性特性;在沉水植物冠层交界处及挺水植物的茎杆和枝叶分叉处,紊流强度及雷诺应力均出现最大值;在一定条件下沉水植物和挺水植物均能抑制底泥再悬浮,但当雷诺数达到一定数值时,水生植物的存在反而加剧了底泥的再悬浮,与挺水植物相比,沉水植物对底泥再悬浮的抑制效果要更好.
    Abstract: Under certain hydrodynamic conditions,different species of aquatic plants will have different impacts on the flow structure and sedmient re-suspension due to the differences in plant morphology.In this study,the sediment collected from the Taihu Lake is placed in a glass tank planting with emergent and submerged macrophytes calam us and water fern.Using the flume expermients,the turbulent flow in the open channel with macrophytes is measured by a three-dmiensional Acoustic Doppler Velocmieter(ADV).The analysis of flow turbulence and sediment re-suspension is conducted.The results show that the vertical velocity distribution has different regularities in open-channel flow with emergent and submerged mcrophytes.Both turbulence intensity and Reynolds Number exhibit obvious anisotropy,and their maximum values are found to be at the junction of submerged plant canopy and at the bifurcation of emergent plant stems and branches,respectively.The sedmient re-suspension process can be inhibited by the presence of emergent and submerged macrophytes under certain conditions.However,when the Reynolds Number reaches a certain value,the presence of these macrophytes can actually exacerbate the sedmient resuspension process.In comparison with emergent plants,submerged mcrophytes would be more effective ininhib iting sedi ent re-suspension.
    • HTML全文
    • 参考文献(16)
  • [1] VERMAAT J E,SANTAMARIA L,ROOS P J.Water flow across and sediment trapping in submerged macrophyte beds of contrasting growth form[J].Archiv fur Hydrobiologie,2000,148:549-562.
    [2] WANG Chao,ZHU Ping,WANG Pei-fang,et al.Effects of aquatic vegetation on flow in the Nansi Lake and its flow velocity modeling[J].Journal of Hydrodynamics:Ser B,2006,18(6):640-648.
    [3] 李艳红,李栋,范静磊.含淹没植物河流水流紊动强度最大值及其影响因素[J].水科学进展,2007,18(5):706-710.(LI Yan-hong,LI Dong,FAN Jing-lei.Turbulence intensity maximum and its influence factors in submerged river flow with plant[J].Advances in Water Science,2007,18(5):706-710.(in Chinese))
    [4] 刘云.流经柔性植物的明渠水流特性影响试验研究[D].南京:河海大学,2006.(LIU Yun.The experimental study on the flow characteristics of open channel with the flexible vegetation[D].Nanjing:Hohai University,2006.(in Chinese))
    [5] 顾峰峰,倪汉根,戚定满.高棵水生植物的阻力系数在非淹没与淹没条件下的相互换算[J].水科学进展,2007,18(6):823-828.(GU Feng-feng,NI Han-gen,QI Ding-man.Transition of long-stalk vegetation resistance coefficient between unsubmerged condition and submerged condition[J].Advances in Water Science,2007,18(6):823-828.(in Chinese))
    [6] 邱秀云,阿不都外力,程艳,等.植物"柔性坝"对水流的影响试验研究[J].水利水电技术,2003,34(9):62-65.(QIU Xiuyun,ABDUWALI,CHENG Yan,et al.Experiment research on the flow characteristics of vegetation flexible dam[J].Water Besources and Hydropower Engineering,2003,34(9):62-65.(in Chinese))
    [7] 刘诚,沈永明.水生植物对水沙运动影响的三维湍流模型[J].水科学进展,2008,19(6):851-856.(LIU Cheng,SHEN Yongming.3D turbulence model for the flow and sediment transport with aquatic vegetation[J].Advances in Water Science,2008,19(6):851-856.(in Chinese))
    [8] 吴福生,王文野,姜树海.含植物河道水动力学研究与进展[J].水科学进展,2007,18(3):456-461.(WU Fu-sheng,WANG Wen-ye,JIANG Shu-hai.Hydrodynamics development in vegetated open channel[J].Advances in Water Science,2007,18(3):456-461.(in Chinese))
    [9] DEITER C D.The importance of emergent vegetation in reducing sedimentresus Pension in wetlands[J].Journal of Freshwater Ecology,1990,5:467-473.
    [10] HORPPILA J,NURMINEN L.The effete of an emergent macrophyte(Typha angustifolia)on Sediment in a shallow north temperate lake[J].Freshwater Biology,2001,46:1447-1455.
    [11] HORPPILA J,NURMINEN L.Effects of submerged macrophytes on sediment resuspension and internal phosphorus loading in Lake Hiidenvesi(Southem Finland)[J].Water Research,2003,37:4468-4474.
    [12] HORPPILA J,NURMINEN L.Effects of different macrophyte growth forms on sediment and P resuspension in a shallow lake[J].Hydrobiologia,2005,545:167-175.
    [13] JAMES W F,BARKO J W,BUTLER M G.Shear stress and sediment resuspension in relation to submersed macrophyte biomass[J].Hydrobiologia,2004,515:181-191.
    [14] JAMES W F,BEST E P,BARKO J W.Sediment resuspension and light attenuation in Peoria Lake:Can macrophytes improve water quality in this shallow system?[J].Hydrobiologia,2004,515:193-201.
    [15] 厉恩华.大型水生植物在浅水湖泊生态系统营养循环中的作用[D].北京:中国科学院研究生院,2006.(LI En-hua.Effcts of aquatic macrophytes on nutrient cycleing in shallow freshwater lake ecosystem[D].Beijing:Graduate School of Chinese Academy of Sciences,2006.(in Chinese))
    [16] HUANG Pei-sheng,LIU Zheng-wen,HAN Bo-ping.Floating-leaved macrophyte(Trapa quadrispinosa Roxb)beds have significant effects on Nitrogen resuspension in Lake Taihu[J].Hydrobiologia,2007,581:189-193.
