三维PIV技术在吸入涡流态测量中的应用

李永, 吴玉林, 袁辉靖, 潘海林

李永, 吴玉林, 袁辉靖, 潘海林. 三维PIV技术在吸入涡流态测量中的应用[J]. 水科学进展, 2007, 18(3): 368-373.
引用本文: 李永, 吴玉林, 袁辉靖, 潘海林. 三维PIV技术在吸入涡流态测量中的应用[J]. 水科学进展, 2007, 18(3): 368-373.
LI Yong, WU Yu-lin, YUAN Hui-jing, PAN Hai-lin. Application of 3-D-PIV in measuring the entrained vortex[J]. Advances in Water Science, 2007, 18(3): 368-373.
Citation: LI Yong, WU Yu-lin, YUAN Hui-jing, PAN Hai-lin. Application of 3-D-PIV in measuring the entrained vortex[J]. Advances in Water Science, 2007, 18(3): 368-373.

三维PIV技术在吸入涡流态测量中的应用

详细信息
    作者简介:

    李永(1977- ),男,山东临沂人,工程师,博士,主要从事流动测量和微重力下流体特性的研究.E-mail:ly00@mails.tsinghua.edu.cn

  • 中图分类号: TV134

Application of 3-D-PIV in measuring the entrained vortex

  • 摘要: 为了研究进水口前吸入涡的流动特性以及不同结构的进水口对吸入涡的影响,对水平进水口前的吸入涡流动进行了三维PIV测量.测量时应用折射率校正法解决了不同介质中进行三维PIV试验时所产生的粒子成像不清晰的问题,并采用多次成像标定法来减小垂直方向上的速度测量误差.通过该试验,得到进水口前吸入涡的三维速度分布规律,并得出后壁面角度与吸入涡大小和强弱关系.试验表明,后壁面角度为30°的进水口比角度为0°进水口更能有效的阻止吸入涡发生,因此可以通过加大后壁面的夹角的方式来削弱进水口处的吸入涡.
    Abstract: In order to study the entrained vortex flow and get the influence of the structure of the intake on it,the 3-D-PIV technique is used to measure this kind of flow near the horizontal intake.The image of the particles got by 3-D-PIV experiment in two media is unclear for the difference of refractivity in different media.So the refractivity-revised method is used to solve the problem.And the multi-step calibrated method is used to improve the measurement precision of the w vector.In the experiments,the distributions of the 3-D velocities of the entrained vortex are obtained.The relation between the entrained vortex and the structure of the intake is also found.Results show that the intake with 30° angle chest wall can prevent the entrained vortex effectively than that with 0° angle chest wall,so it is a good idea,through changing the angle of the chest wall,to prevent the entrained vortex near the intake.
  • [1] 盛森芝,徐月亭,袁辉靖.近十年来流动测量技术的新发展[J].力学与实践,2002(24):1-14.
    [2] Adrian R J.Multi-point optical measurements of simultaneous vectors in unsteady flow a review[J].Heat and Fluid Flow,1986,Vol 127(7):127-145.
    [3] Grant I,Fu S,Pan X,et al.The application of an in-line,stereoscopic,PIV system to 3-component measurements[J].Experiments in Fluids,1995(19):214-221.
    [4] Guezenned Y G,Brodkey R S,Trigui N,et al.Algorithms for fully automated three-dimensional particle tracking velocimetry[J].Experiments in Fluids,1994(17):209-219.
    [5] 李永.进水口前空气吸入涡流态的试验研究和数值模拟[D].北京:清华大学,2005.
    [6] Echavez G,McCann E.An experimental study on the free surface vertical vortex[J].Experments in Fluids,2002(33):414-421.
计量
  • 文章访问数:
  • HTML全文浏览量:
  • PDF下载量:
  • 被引次数: 0
出版历程
  • 收稿日期:  2006-02-10
  • 修回日期:  2006-06-29
  • 刊出日期:  2007-05-24
