渠道分水扰动可预知算法设计与仿真

尚毅梓; 吴保生; 李铁键; 王光谦

渠道分水扰动可预知算法设计与仿真

清华大学水沙科学与水利水电工程国家重点实验室, 北京, 100084

基金项目: 国家重点基础研究发展计划(973)资助项目(2007CB714100)

详细信息

作者简介:
尚毅梓(1983- ),男,博士,助理研究员,主要从事水力学及河流动力学方面研究.E-mail:syz05@mails.tsinghua.edu.cn

中图分类号: TV135.3
计量
- 文章访问数: 263
- HTML全文浏览量: 33
- PDF下载量: 620
出版历程
- 收稿日期: 2010-06-03
- 刊出日期: 2011-03-24

Design and simulation of a foreseeable algorithm for canals

State Key Laboratory of Hydroscience and Engineering, Tsinghua University, Beijing 100084, China

Funds: The study is financially supported by the National Basic Research Program of China(No.2007CB714100)

摘要

摘要: 维持控制点水位稳定是保证输水渠道安全有效运行的前提.以控制点水位偏差为主要抑制因子,基于线性二次型(LQR)指标,构建了渠道系统水位偏差、偏差变率和流量控制的全状态空间模型,将加入预测模块的线性二次型算法在渠道系统的全状态空间中进行分析和综合,提出了扰动可预知模型的构造方法.通过脉冲响应测试来加深对算法结构的理解,使用南水北调中线电子渠道平台对算法有效性进行验证,验证结果表明,该算法在渠道运行工况改变后,仍能够维持渠道的稳定运行,算法设计极具潜在的应用价值.
- 渠道运行控制 /
- 南水北调中线工程 /
- 预测算法 /
- 电子渠道
Abstract: Water level hold at specified locations within each reach is of the utmost importance for reliable and efficient management in a channel.A new algorithm for the control of unsteady flows in open channels is presented.An innovative control method is first analyzed,and then synthesized to construct a foreseeable module.The algorithm can thus be obtained by implanting the predicative module into a linear quadratic regulator(LQR).Using LQR,the canal operation problem can thus be reformulated as an optimal control problem,which regulates the gate discharge using the water level error as its constraints.The logical structure of the new algorithm is identified using an impulse response test,and the performance of the algorithm is tested on the platform of the "digital canal of the middle route of south to north water diversion project".The result shows that the algorithm performs well,is able to cope with the planned demand for large quantities of water,and is potentially useful for real applications.
- canal control /
- the middle route of South to North Water Transfer Project /
- predicative algorithm /
- digital canal

HTML全文

参考文献(10)

[1]	吴保生,尚毅梓,崔兴华,等.渠道自动化控制系统及其运行设计[J].水科学进展,2008,19(5):746-755.(WU Baosheng,SHANG Yi-zi,CUI Xing-hua,et al.Automatic canal control system and its operation and design[J].Advances in Water Science,2008,19(5):746-755.(in Chinese))
[2]	方神光,吴保生,傅旭东等.南水北调中线输水渠道中分水口的影响[J].清华大学学报:自然科学版,2007,47(9):1452-1456.(FANG Shen-guang,WU Bao-sheng,FU Xu-dong,et al.Effect of devisions in the middle route of the South to North Water Transfer Project[J].Journal of Tsinghua University:Science and Technology,2007,47(9):1452-1456.(in Chinese))
[3]	LOZANO D,ARRANJA C,RLJO M,et al.Simulation of automatic control of an irrigation canal[J].Agricultural Water Management,2010,97:91-100.
[4]	VALENTIN G M,BENEDE J R.A control tool for irrigation canals with scheduled demands[J].Journal of Hydraulic Research,2008,46(E1):152-167.
[5]	魏加华,王光谦,陈志祥,等.南水北调中线电子渠道平台建设[J].南水北调与水利科技,2007,5(2):28-52.(WEI Jia-bus,WANG Guang-qian,CHEN Zhi-xiang,et al.Digital canal of the middle route of South to North Water Diversion Project[J].South to North Water Transfer and Water Science & Technology,2007,5(2):28-52.(in Chinese))
[6]	方神光,李玉荣,吴保生.大型输水渠道闸前常水位的研究[J].水科学进展,2008,19(1):68-71.(FANG Shen-guang,LI Yu-rong,WU Bao-sheng.Constant water levels at the upstream of sluice gates in a large-scale transferring channel[J].Advances in Water Science,2008,19(1):68-71.(in Chinese))
[7]	史哲,马吉明,郑双凌.节制闸控制下宽浅渠道内的非恒定流[J].南水北调与水利科技,2007,5(6):21-24.(SHI Zhe,MA Ji-ming,ZHENG Shuang-ling.The unsteady flow in the wide shallow open channel with controlling gates[J].South to North Water Transfer and Water Science & Technology,2007,5(6):21-24.(in Chinese))
[8]	OMER F D.Control of transient flow in irrigation canals using Lyapunov fuzzy filter-based Ganssian regulator[J].International Journal for Numerical Methods in Fluids,2006,50:491-509.
[9]	李义天.河网非恒定流隐式方程组的汊点分组解法[J].水利学报,1997(3):49-57.(LI Yi-tian.A junctions group method for unsteady flow in multiply connected networks[J].Journal of Hydraulics Engineering,1997(3):49-57.(in Chinese))
[10]	余国安.闸门调控下的灌溉渠道非恒定流数值模拟研究[D].杨凌:西北农林科技大学,2004.(YU Guo-an.Numerical simulation of sluice gate regulated unsteady flow in irrigation canals[D].Yangling:Northwest A&F University,2004.(in Chinese))
