GIS/RS based distributed hydrological modeling,2, model test and application
-
摘要: GIS/RS是流域水文过程分布式模拟的重要技术支撑。结合泾河流域的实例研究,探讨了GIS支持下,基于栅格DEM流域水文特征的获取,降水、气温等资料的空间插值,以及土壤、植被等下垫面信息在水文模拟单元上的耦合。在此基础上,应用分布式水文模型对泾河流域的水文过程进行模拟。结果表明:所建模型结构上是合理的,在产流计算中泾河25个子流域在水量平衡方面误差均小于5%。潜在蒸发的模拟在趋势上与实测过程基本一致。径流模拟在4个检验站点上与实测过程的相关系数达到0.84～0.93。模型基本能够满足水资源规划与管理的需要。Abstract: GIS/RS is an important technology support for distributed hydrological modeling in a watershed. This paper carries out a case study on the Jinghe River which is the second grade tributary of the Yellow River. With the support of GIS,the watershed characters including slope,river networks and river length are extracted from the digital elevation model with a resolution of 100-by-100 meters. Also,soil and land use information are parameterized to each sub-watershed. And precipitation, temperature are interpolated to all sub-watersheds. By coupling all the distributed parameters,the hydrological processes of the Jinghe River basin are simulated. The results show that the errors of water balance are less than 5% for all 25 sub-watersheds. which indicates the rationality of the model. The potential evapotranspiration simulated is quite close to the observation. As for the four hydrological stations,the correlation coefficient between daily runoff observed and simulated is about 0.84～0.93.
-
Keywords:
- GIS /
- RS /
- distributed hydrological modeling /
- Jinghe basin
-
-
[1] 冉大川,刘斌,罗全华,等.泾河流域水沙变化水文分析[J].人民黄河,2001,23(2):9-11. [2] 王小艳,高建恩,安梦雄.泾河水沙基本特性分析[J].西北水资源与水工程,2001,12(3):21-24. [3] Jenson S K,Domingue J O.Extracting Topographic Structure from Digital Elevation Data for Geographic Information System Analysis[J].Photogrammetric Engineering and Remote Sensing,1988,54(11):1 593-1 600. [4] Tarboton D G,Bras R L,I Rodriguez-Iturbe.On the Extraction of Channel Networks from Digital Elevation Data[J].Hydrological Processes,1991,5: 81-100. [5] Nelson E J,Smemoe C M,Zhao B.A GIS Approach to Watershed Modeling in Maricopa County[A].Arizona American Society of Civil Engineers.Water Resources Planning and Management Conference[C].American Society of Civil Engineers,USA,1999,6-10. [6] Fairfield J,Leymarie P.Drainage Networks from Grid Digital Elevation Models[J].Water Resources Research,1991,30(6):1 681-1 692. [7] Freeman T G.Calculating catchment area with divergent flow based on a regular grid[J].Comput Geosci,1991,17(3):413-422. [8] Costa-Cabral M C,Burges S J.Digital elevation model networks (DEMON): A model of flow over hill slopes for computation contributing and dispersal areas[J].Water Resources Research,1994,30(6): 1 681-1 692. [9] 王中根,刘昌明,左其亭,等.基于DEM的分布式水文模型构建方法[J].地理科学进展,2002,21(5):430-439. [10] 王中根,郑红星,刘昌明,等.基于GIS/RS的流域水文过程分布式模拟——Ⅰ模型的原理和结构[J].水科学进展,2004,15(4):501-505.
